Voltage: DC9~36V/AC24~48V/AC85~260V
Dimension: 350x350x150mm
Ambient temperature: -40℃~+60℃
Degree of Protection: IP66/IP68 (2m, 2h) / IP69
Hazardous Ratings: Zone 1/2, Zone 21/22

1. The main body of the cabin (double-layer structure,
with insulation and fire-resistant materials filled in the middle)
2. Indoor hazardous gas concentration monitoring system
3. Sound and light alarm interlocking system
4. Equipment power distribution system
5. Power and remote signal conversion signal box
6. Positive pressure control system
7. Hazardous Ratings: Zone 1/2, Zone 21/22

1. Control Power Supply: 220VAC,380W
2. Operating Positive Pressure Range: 150Pa–900Pa
900Pa: Automatic air exhaust，<150Pa: Automatic air replenishment
3. Critical Positive Pressure Values: 1000Pa: Manual air exhaust
<70Pa: Automatic power cut-off
4. Air Source: Clean air or protective gas with pressure ≥0.4MPa
5. Hazardous Ratings: Zone 1/2, Zone 21/22

1. Housing is die-cast from aluminum alloy,
or welded from stainless steel /Q235 carbon steel,
with surface treated by powder coating or spray painting.
2. Equipped with switches, ammeters, indicator lights, push buttons, PLCs, low-power inverters, contactors and other instruments.
3. Installation types: wall-mounted and floor-standing.
4. Wiring via steel conduits or cables.
5. Overall dimensions are customizable according to actual requirements.
6. Hazardous Ratings: Zone 1/2, Zone 21/22

Braking Distance: ≤0.5 m
Straight-Line Speed: 0-1.4m/s
Turning Diameter: 160cm
Climbing Ability: ≤25°
Obstacle Crossing Ability: ≤10 cm
Wading Ability: ≤12cm
Charging Time: ≤3 h
Endurance Capability: ≤5h
Primary Navigation Method: Laser Navigation
Positioning Accuracy: ≤±3 cm
Hazardous Ratings: Zone 1/2, Zone 21/22

Braking Distance: Straight: ≤0.1m，climbing: ≤0.1m
Straight-Line Speed: 0-2m/s
Turning Diameter: 80cm
Climbing Ability: ≤45°
Charging Time: ≤10km
Endurance Capability: ≤5h
Primary Navigation Method: Odometer + Hall Sensor + RFID
Positioning Accuracy: ≤±1 cm
Hazardous Ratings: Zone 1/2, Zone 21/22

Wattage Range: 10W-60W (R2) ; 20W-100W (R4)
Selectable Power: 20W/30W/40W (R2) ; 40W/50W/60W (R4)
Lumens Per Watt: 180lm/W
Lumen Output: Max. 10800lm

Input Voltage: 120-277VAC/120-347VAC/277-480VAC
12-36VDC/120-400VDC

Selectable CCT: 4000K/5000K/6500K， Other CCT options available
Beam Angle: 120°
Hazardous Ratings: CID2/CIID1/CIID2/CIII

Wattage Range: 20W-150W (Q1) ; 20W-240W (Q2)
Selectable Power: 60W/80W/100W (Q1) ; 120W/150W/200W (Q2)
Lumens Per Watt: 150lm/W
Lumen Output: Max. 22500lm (Q1) ; Max. 36000lm (Q2)

Input Voltage: 120-277VAC/120-347VAC/277-480VAC
12-36VDC/120-400VDC

Selectable CCT : 4000K/5000K/6500K，Other CCT options available
Beam Angle: Standard: 120°, Optional : 40°/60°/90°/T2/T3/T5
Hazardous Ratings: CID2/CIID1/CIID2/CIII

Wattage Range: 20W-100W (I2) ; 20W-200W (I4)
Selectable Power: 30W/50W/60W (I2) ; 60W/80W/100W (I4)
Lumens Per Watt: 150lm/W
Lumen Output: Max. 15000lm (I2) ; Max. 30000lm (I4)

Input Voltage: 120-277VAC/120-347VAC/277-480VAC
12-36VDC/120-400VDC

Selectable CCT : 4000K/5000K/6500K，Other CCT options available
Beam Angle: Standard: 120°, Optional : 30°/45°/60°/90°/T2/T3/T5
Hazardous Ratings: CID1/CID2/CIID1/CIID2/CIII

Wattage Range: 20W-100W (H2) ; 20W-200W (H4)
Selectable Power: 30W/40W/60W (H2) ; 40W/60W/80W (H4)
Lumens Per Watt: 160lm/W (H2) ;180lm/W (H2)
Lumen Output: Max. 16000lm (H2) ; Max. 36000lm (H4)

Input Voltage: 120-277VAC/120-347VAC/277-480VAC
12-36VDC/120-400VDC

Selectable CCT : 4000K/5000K/6500K，Other CCT options available
Beam Angle: Standard: 120°, Optional : 40°/60°/90°/T2/T3/T5
Hazardous Ratings: CID2/CIID1/CIID2/CIII

Wattage Range: 10W-75W (FLG2) ; 20W-150W (FLG4)
Selectable Power: 30W/40W/60W (FLG2) ; 80W/100W/120W (FLG4)
Lumens Per Watt: 180lm/W
Lumen Output: Max. 13500lm (FLG2) ; Max. 27000lm (FLG4)
Input Voltage:120-277VAC/120-347VAC/277-480VAC
Selectable CCT : 4000K/5000K/6500K，Other CCT options available
Beam Angle: Standard: 120°, Optional : 25°/55°/90°/T2/T3/T4
Hazardous Ratings: CID2/CIID1/CIID2/CIII

Wattage Range: 15W-20W (FLD1-2); 15W-60W (FLD2-2)
15W-60W (FLD1-4) ; 15W-120W (FLD1-4)

Selectable Power: 40W/50W/60W（FLD1-2/FLD2-2/FLD1-4)
50W/60W/80W (FLD1-4) ;

Lumens Per Watt: 170lm/W

Lumen Output: Max. 3400lm (FLD1-2); Max. 10200lm (FLD2-2)
Max.10200lm (FLD1-4); Max. 20400lm (FLD2-4)

Input Voltage: 120-277VAC/120-347VAC/277-480VAC
12-36VDC/120-400VDC

Selectable CCT : 4000K/5000K/6500K，Other CCT options available
Beam Angle: 120° Hazardous Ratings: CID2/CIID2/CIII
