Explosion-Proof Lighting

Wattage Range: 80W-280W (D3) ; 20W-100W (D4)
Selectable Power:120W/150W/200W (D3) ; 60W/80W/100W (D4)
Lumens Per Watt: 160lm/W (D3) ; 140lm/W (D4)
Lumen Output: Max. 44800lm (D3) ; Max.14000lm (D4)

Input Voltage: 120-277VAC/120-347VAC/277-480VAC
12-36VDC/120-400VDC

Selectable CCT: 4000K/5000K/6500K， Other CCT options available
Beam Angle: Standard: 120°, Optional : 30°/40°/60°/90°/T2/T3/T5
Hazardous Ratings: CID1/CID2/CIID1/CIID2/CIII

Wattage Range: 20W-600W

Selectable Power: 40W/60W/80W (A2) ; 80W/100W/150W (A)
120W/150W/200W(A3); 200W/250W/300W(A4)

Lumens Per Watt: 160lm/W (A2) ; 170lm/W (A) ; 175lm/W (A3/A4)

Lumen Output: Max.16000lm (A2) ; Max. 25500 lm (A)
Max.42000 lm (A3) ; Max. 105000 lm (A4)

Input Voltage: 120-277VAC/120-347VAC/277-480VAC
12-36VDC/120-400VDC

Selectable CCT: 4000K/5000K/6500K， Other CCT options available
Beam Angle: Standard: 120°, Optional : 30°/40°/60°/90°/T2/T3/T5
Hazardous Ratings: CID2/CIID1/CIID2/CIII

Wattage Range: 20W-100W
Selectable Power: 40W/50W/60W
Lumens Per Watt: 150lm/W
Lumen Output: Max. 15000 lm

Input Voltage: 120-277VAC/120-347VAC/277-480VAC
12-36VDC/120-400VDC

Selectable CCT: 4000K/5000K/6500K， Other CCT options available
Beam Angle: Standard: 120°, Optional : 40°/60°/90°/T2/T3/T5
Hazardous Ratings: CID2/CIID1/CIID2/CIII

Wattage Range: 10W-60W (RL2) ; 20W-100W (RL4)
Selectable Power: 20W/30W/40W (RL2) ; 40W/50W/60W (RL4)
Lumens Per Watt: 180lm/W
Lumen Output: Max. 10800lm

Input Voltage: 120-277VAC/120-347VAC/277-480VAC
12-36VDC/120-400VDC

Selectable CCT: 4000K/5000K/6500K， Other CCT options available
Beam Angle: 120°
Hazardous Ratings: CID2/CIID1/CIID2/CIII

Input: 100-277VAC, 50/60Hz
Output: 3VDC Rated Power: 3W
Emergency Time: 3 hours
Protection: IP66
Housing Material: Aluminum
Hazardous Ratings: Zone 1/2/21/22

Input: 100-277VAC, 12-36VDC, 50/60Hz
Output: 3VDC
Rated Power: 10W
Emergency Time: 3 hours
Response Time: <0.5
Charging Time: ≤24 hours
Housing Material: Glass Fiber Reinforced Polyester Resin
Hazardous Ratings: Zone 1/2/21/22

Input: 200-250VAC, 50/60Hz
Rated Power: 10W-100W
Efficiency: 108-126lm/W
Beam Angle: 40°/ 60° / 90° / 120°
CCT: 2700K-6500K
Housing Material: Aluminum 6063
Diffuser Material: Polycarbonate(PC)
Protection: IP66/IK10 Hours salt spray
Hazardous Ratings: Zone 1/2/21/22

Input: 100-277VAC, 50/60Hz
Rated Power: 10W-27W
Efficiency: 100lm/W
Beam Angle: 40°/ 60° / 90° / 120°
CCT: 3000K-6500K
Housing Material: Copper-free Aluminum
Diffuser Material: Tempered glass
Protection: IP66/IK08
Hazardous Ratings: Zone 1/2/21/22

Input: 100-277VAC, 200-277VAC, 125-270VDC, 50/60Hz
Rated Power: 20W-600W
Efficiency: 140lm/W
Beam Angle: 40°/ 60° / 90° / 120°
CCT: 1800K-6500K
Housing Material: Copper-free Aluminum
Hardware: Stainless Steel
Protection: IP66/IK08 (glass cover)/IK10 (with wire guard)
Hazardous Ratings: Zone 1/2/21/22

Input: 100-277VAC, 200-277VAC, 125-270VDC, 50/60Hz
Rated Power: 20W-600W
Efficiency: 140lm/W
Beam Angle: 40°/ 60° / 90°
CCT: 1800K-6500K
Housing Material: Copper-free Aluminum
Hardware: Stainless Steel
Protection: IP66/IK08 (glass cover)/IK10 (with wire guard)
Hazardous Ratings: Zone 1/2/21/22

Wattage Range: 10W-60W (R2) ; 20W-100W (R4)
Selectable Power: 20W/30W/40W (R2) ; 40W/50W/60W (R4)
Lumens Per Watt: 180lm/W
Lumen Output: Max. 10800lm

Input Voltage: 120-277VAC/120-347VAC/277-480VAC
12-36VDC/120-400VDC

Selectable CCT: 4000K/5000K/6500K， Other CCT options available
Beam Angle: 120°
Hazardous Ratings: CID2/CIID1/CIID2/CIII

Wattage Range: 20W-150W (Q1) ; 20W-240W (Q2)
Selectable Power: 60W/80W/100W (Q1) ; 120W/150W/200W (Q2)
Lumens Per Watt: 150lm/W
Lumen Output: Max. 22500lm (Q1) ; Max. 36000lm (Q2)

Input Voltage: 120-277VAC/120-347VAC/277-480VAC
12-36VDC/120-400VDC

Selectable CCT : 4000K/5000K/6500K，Other CCT options available
Beam Angle: Standard: 120°, Optional : 40°/60°/90°/T2/T3/T5
Hazardous Ratings: CID2/CIID1/CIID2/CIII
